JACK, 1/4", TIP/SLEEVE 4 PIN, PC
MOUNT. Mono, 4 pin. Fits certain Fender™, Hartke™ and Vox™ amp
models 1988 - present. Nut and washer are included. Replacement nut/washer set is the JN-916.
Part # J-506
$2.89
Click on photo for
larger view
SAVE WITH
MULTIPACK! JACK, 1/4",
TIP/SLEEVE 4 PIN, PC MOUNT, Fender™STYLE 1988 - Present.
PACK OF 6 JACKS. Fender™
Style PC mount 1/4" jack. Mono, 4 pin. Fits certain Fender™ amp models 1988 - present. Also commonly found on Hartke™™ amps. Fender™ part numbers 0990912000, 0037036000, 990912,
and 037036.
Pack of 6 Jacks, including nuts and washers.
Replacement nut/washer is the JN-916.
Part # J-506-6
$15.95
(For 6 Jacks)
Click on photo for
larger view
SAVE WITH
ASSORTMENT
MULTIPACK! THIS PACK CONTAINS THREE J-506 (4 PIN) AND THREE J-507 (9-PIN)
JACKS. Many amps contain both the 4 pin and the 9 pin jacks. This
assortment gives you 3 of each jack ... Three J-506, and three J-507.
Replaces Fender™ part numbers 0990912000, 0037036000, 990912, 037036, and
0990913000, 025931, 990913. Pack of 6 Jacks, including nuts and washers
Part # J-5067-6
$14.99
(For 3 J-506 Jacks
and 3 J-507 Jacks)
Click on photo for
larger view
JACK, 1/4", TIP/RING/SLEEVE, 9 PIN, PC MOUNT, Fender™
STYLE 1988 - Present. Fender™ PCB mount 1/4" jack. Stereo, 9 pin. Fits certain Fender™ amp models 1988 - present. Used as the input jack on the Ultimate Chorus, Princeton Chorus, and similar solid-state models from the 1990's.
Replaces Fender™ part numbers 031570, 031570000, 0990913000, 025931, 990913, and 0025931000.
Also used by other amp manufacturers. Click
here for specifications. Includes nut and
washer. Replacement
nut/washer set is the JN-916.
Part # J-507
$3.05
Click on photo for
larger view
SAVE WITH
MULTIPACK! JACK, 1/4",
TIP/SLEEVE 9 PIN, PC MOUNT, Fender™
STYLE 1988 - Present.
PACK OF 6 JACKS. Fender™
style PC mount 1/4" jack.
Stereo, 9 pin. Fits certain Fender™ amp models 1988 - present. Also commonly found on Hartke™ amps.
Used as the input jack on the Ultimate Chorus, Princeton Chorus, and similar
solid-state models from the 1990s. Replaces Fender™ part numbers 0990913000, 025931, 990913, and 0025931000.
Nuts and washers included.
Click
here for specifications.
Pack of 6 Jacks.
Part # J-507-6
$16.95
(For 6 Jacks)
Click on photo for
larger view
JACK,
1/4", Fender™, 4-PIN.
Used as the input jack on some versions of the Fender™
Sidekick amp series.
Includes nut and washer.
Part # J-6075
$5.95
Click on photo for
larger view
JACK, 1/4", 7-PIN, HEADPHONE,
USED IN Marshall™, FENDER™, YAMAHA™ & OTHERS, PC MOUNT Used as the headphone jack in the Marshall™ G15RCD and G30RCD.
Original Marshall™ part number V4550. Used as the headphone jack in Yamaha models YPR6, HE6, PSR520, YPR8, and
other models. Original Yamaha part number LB10187R. Used
in the Fender Sidekick Bass Amp as the headphone jack, Fender part number
022923. Used
in the Korg Triton Studio, Triton extreme, M3, CI8600, CI9600. Korg part
number 454005600, YKB21-5006. Casio Part # 36120665. Note: No trim ring at jack opening.
Includes nut and washer. Part # J-540
$6.70
Click on photo for
larger view
JACK,
9-PIN Low Profile, 1/4",
Fender™.
Used in a few unique Fender models. Nut and washer are NOT included.
Chrome trim ring. Jack data here.
Includes nut and washer. Part # J-560F
$6.50
Click on photo for
larger view
JACK, 1/4",
TIP/SLEEVE 3 PIN, PC MOUNT, Used in Fender™
Squire and Sidekick Amps from the Rivera-era (80s, early 90s) PC mount 1/4" jack. Mono, 3 pin. Also used in some Fender™ Squire™ amps,
such as the Champ 12 Champ 15, 15G and Sidekick 15 and 15B. Not used
in the BXR300C or BXR300R. Used in the Marshall™
MS-2 Mini Amp. Nut and washer are included. Replacement nut/washer set is the JN-916.
Part # J-506B
$5.95
Click on photo for
larger view
JACK, 1/4",
TIP/SLEEVE 3 PIN, PC MOUNT, Used in Fender™
BXR-300C and BXR-300R from the Rivera-era (80s, early 90s) PC mount 1/4" jack. Mono, 3 pin. Note unusual pin
arrangement - different from the 3-pin J-506B. Replaces Fender part
number 025929. Nut and washer are included.
Part # J-506BXR
$5.95
Click on photo for
larger view
Available with or without nut and
washer.
JACK, 1/4", TIP/RING/SLEEVE, 7 PIN, PC MOUNT,
Fender™,
Hartke™,
B-52™,
Randall™,
and Crate™
Amps.
Fender™, Hartke™, Randall™, B-52™ or Crate™ PCB mount 1/4" jack.
7 pins. Fits several Hartke™ amp models 1990
- present, and several Crate™
models, especially in the GX series. Used
in the Fender™
SKX65R and SKX100R for the input
jacks.
Used in some Fender™
Squier and Sidekick amps as the headphone jack. Replaces Hartke™
part number 350023 and 300519. Replaces
Fender™
part number 022923. Replacement nut/washer set is the JN-916.
Available with or without nut/washer - choose in "Options"
Part # J-545
Starting at
$5.95
Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT
MONO, PC MOUNT, Switchcraft™
STYLE, NON-ISOLATED Common PC mount input jack. 3 pins, mono, tip shunt.
Shield tied to chassis mount.
Used in many amplifiers. Fender™ part number 030771. Nut
and washer included.
Part #J-112APC
$5.95
Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT
MONO, PC MOUNT, Switchcraft™
STYLE, ISOLATED
NYLON BUSHING Found in many applications. 3 pins, mono, tip shunt.
Isolated sleeve. Used as the `Fat` footswitch jack in the Blues Junior. Fender™ part number 0027674000.
Nut and washer included.
Part #J-N112APC
$6.95
Click on photo for
larger view
ECONOMY JACK, 1/4", PC MOUNT, STEREO, 5 PINS, SWITCHED, METAL BUSHING. Both tip and
ring conductors are switched (normally closed). 5 pins. Used in Peavey™,
Mesa/Boogie, Mackie and
many other brands.
Replaces Switchcraft 114BPCX and 114BPCSX. Nut and washer included.
Part #J-529
$2.99
Click on photo for
larger view
JACK, 1/4", STEREO, CLOSED CIRCUIT, PC
BOARD MOUNTING, Switchcraft™,
METAL BUSHING Common PC mount jack in guitar amps, mixers, etc. 5 pins for
inserting into PC board,
stereo, tip and ring shunt. Shield tied to chassis mount. Often used
for headphone jacks, insert jacks, FX loop jacks, etc. Nut
and washer included. Genuine Switchcraft™.
Part #J-114B-PC
$6.95
Click on photo for
larger view
JACK, 1/4", CLOSED CIRCUIT
STEREO, PC BOARD MOUNTING, Switchcraft™,
METAL BUSHING Tip is switched (normally
closed), ring conductor is not switched. 4 pins for inserting into PC
board, metal bushing. Nut and washer included. Genuine Switchcraft™
Part #J-113B-PC
$6.95
Click on photo for
larger view
JACK, 1/4", CLOSED CIRCUIT
STEREO, PC BOARD MOUNTING, Switchcraft™,
METAL BUSHING Tip is
open, ring is switched (normally
closed). 4 pins for inserting into PC board, metal bushing. Unusual arrangement
used in special applications. Nut and washer included. Genuine Switchcraft™
Part #J-113F-PC
$6.95
Click on photo for
larger view
JACK, 1/4", CLOSED CIRCUIT
MONO, HAND WIRED, Switchcraft™
STYLE,
METAL BUSHING Common input jack in guitar amps. T/S
closed circuit, switched, metal bushing, 3 pins for wiring. Nut and washer included.
Fender part number 0066439000. Found in a number of SWR amps as the
input jack.
Part #J-112AX
$4.50
Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT, RIGHT ANGLE PC MOUNT, Switchcraft™
STYLE, NYLON THREADS,
3 PINS Common input jack in Crate™ & Ampeg™,
and in some solid state products from Fender™
during the early 1980s. Nut and washer included. Fender
part number 018594. Part #RN112APC
$5.98
JACK NUT AND WASHER, METAL,
SWITCHCRAFT™ Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the
CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™
blackface and silverface), as well as Peavey™ and Switchcraft™
1/4" jacks. Does NOT fit the 24mm Marshall™ pots. Part #JNUT-38
$0.89
(Set of 1 washer and 1 nut)
Click on photo for
larger view
JACK, 1/4", Marshall™
G SERIES, INPUT, LINE OUT, FOOTSWITCH, PC MOUNT,
HAS RED STRIPE. MONO,
SWITCHED. Used as the
input jack on certain Fender™ SideKick amps, such as the SideKick Chorus 20.
Does not include nut and washer - order separately here.
Replacement nut/washer set ordered separately here. Part # J-531
$4.75
Click on photo for
larger view
JACK,
1/4", CHROME NUT, CLOSED CIRCUIT, PC MOUNT, USED IN FENDER™
CHAMPION 600.
Input jack for the Champion 600 reissue. Stereo T/R/S jack, no
switching. Fender part number 0073909049, 0073909000,
007-3909-049. Nut and washer included.
Part #J-739
$3.95
Click on photo for
larger view
JACK, 1/4", Used in Fender™, PCB, MONO CLOSED CIRCUIT PCB mono closed circuit. Original Fender™ part number 0037117000.
Nut and washer are included. Part #J-512
$8.50
NUT AND WASHER, NICKEL, KOBICONN
OR JALCO TYPE. Fits J-506, J-506A, J-507, J-530, J-531
, J-532, J-533, J-533G,
J-539, J-539G, J-540, J-545, J-6074, J-6075, J-560. Part #JN-916
$0.75
Click on photo for
larger view
JACK,
1/4", MONO 4-PIN, PC MOUNT, Fender™ Fender™
PCB mount 1/4" jack. Tip/Sleeve, 4 pin. Used as the input jacks on the
Fender™
Mustang amps (I through IV). Used as the footswitch jack on the
Ultimate Chorus DSP Amp from 2000-2002. Also used on some Squier™ models.
Nut is included. Original
Fender™ part numbers
0091653000 and 0051658000. Part #J-517
$2.95
Click on photo for
larger view
JACK, 1/4",
STEREO 6-PIN, PC MOUNT, Fender™ Fender™
PCB mount 1/4" jack. Tip/Ring/Sleeve, 6 pin. Used as the effects jacks and
headphone jacks on the
Fender™
Mustang amps (III through V). Also used as the input jacks and all FX Loop
Jacks on the Ultimate Chorus DSP Amp from 2000-2002. Nut is included.
Original
Fender™ part numbers
0091655000 and 0053450000. Part #J-514
$3.50
Click on photo for
larger view
Note:
Nut NOT included - reuse original, or order J-510.
JACK, 1/4", STEREO, PC MOUNT,
TIP/RING/SLEEVE 6 Pins, Fender™ Fender™ PCB mount 1/4" jack.
Fender™ part number 0053450000. Stereo, 6 pin. Fits certain Fender™
amp models 1999 - present. Save money on multiple
jacks with the J-508-6 jack multipack, below.
Nut NOT included. Reuse existing nut or order nut separately as part #J-510. Part #J-508
$2.95
Click on photo for
larger view
Note:
Nuts NOT included - reuse original, or order J-510.
SAVE WITH MULTIPACK! JACKS, 1/4",
TIP/RING/SLEEVE 6-PIN, PC MOUNT, Fender™, SET OF 6 JACKS. Fender™ PCB mount 1/4" jack.
Fender™ part number 0053450000. Stereo, 6 pin. Fits certain Fender™
amp models 1999 - present. Set of 6 Jacks.
Nuts NOT included. Reuse existing nuts or order nuts separately as part #J-510. Part #J-508-6
$12.95
(For Set of 6 Jacks)
Click on photo for
larger view
Note:
Nut NOT included - reuse original, or order J-510.
JACK, 1/4", MONO, REAN TYPE, PC MOUNT, Fender™ Fender™ PCB mount 1/4" jack. Mono, 4 pin. Fits certain Fender™
amp models 1999 - present (including certain jacks on the newer Hot Rod Deluxe &
Deville, and Blues Deluxe & Deville).
Fender™ part number 0051658000.
Save money on multiple jacks with the J-509-6 jack multipack, below.
Nut NOT included. Reuse existing nut or order nut separately as part #J-510. Part #J-509
$2.95
Click on photo for
larger view
Note:
Nut NOT included - reuse original, or order J-510.
SAVE WITH MULTIPACK! JACKS, 1/4", MONO
4-PIN, REAN TYPE, PC MOUNT, Fender™ SET OF 6 JACKS. Fender™ PCB mount 1/4" jack. Mono, 4 pin. Fits certain Fender™ amp models 1999 - present (including certain jacks on the
newer Hot Rod Deluxe & Deville, and Blues Deluxe & Deville).
Fender™ part number 0051658000.
Set of 6 Jacks.
Nuts NOT included. Reuse existing nuts or order nuts separately as part #J-510. Part #J-509-6
$12.95
(For Set of 6 Jacks)
Click on photo for
larger view
JACK, 1/4", STEREO, REAN TYPE, PC MOUNT, Metal 3/8" Threads, Fender™ AMPS 1998 - Present. Fender™ PCB mount 1/4" jack. Stereo, 6 pin. Fender™ part number 0059889000.
Princeton™ Recording Amp, Jazz-King™, TB 600/1200,
Bassman™ TV Series, Super Bassman™ (2012), Machete™, Acoustasonic™ SFX II,
Princeton™ 650, Deluxe™ 900, Stage™ 1000/1600, EVH 5150III, Cyber-Twin™ SE, JazzMaster™
Ultralight, Bassman™ 250, Steel King and Super-Champ™ X2 amplifiers
(1998-present). Identical to J-508 jack above, except for the metallic
threads, which uses a different size nut. Nut and washer are included. Part #J-563
$ 4.75
Click on photo for
larger view
Note:
Nut & Washer NOT included - reuse original, or order JNUT-38.
JACK, 1/4", STEREO, REAN TYPE, PC MOUNT, Metal 3/8" Threads,
Grounding type, Fender™ AMPS 1998 - Present. Fender™ PCB mount 1/4" jack. Stereo, 6 pin. Fender™ part number
0079774000.
Shield grounded to chassis via
metal bushing, tip and ring switched. Nut NOT included. Reuse existing nut or order nut separately as part #JNUT-38. Part #J-564
$ 3.95
Click on photo for
larger view
JACK, 1/4", MONO, OPEN CIRCUIT, WIRED, Switchcraft™ Found in many guitars, effects pedals, amps speaker output. Includes nut and washer. Part #J-11
$4.29
Click on photo for
larger view
JACK, 1/4", MONO, OPEN CIRCUIT, WIRED, Switchcraft™, LONG BUSHING Same as the J-11 jack, but with longer (3/8") threaded bushing for mounting in thicker panels. Includes nut and washer. Part #J-L11
$5.39
Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT (SHORTING), WIRED, Switchcraft™ Found in vintage Fender™ (and other) amps as the input jack.
Also used in the Hot Rod Deluxe/Deville, Blues Deluxe/Deville as the main
speaker out jack. Includes nut and washer. Fender™ part
number 0021550000 (originally 021550). Peavey part number 71466004. Part #J-12A
$4.79
Click on photo for
larger view
JACK, 1/4", MONO, CLOSED CIRCUIT
(SHORTING), WIRED, Switchcraft™, LONG BUSHING Same as the J-12A jack, but with longer (3/8") threaded bushing for mounting in thicker panels. Includes nut and washer. Part #J-L12A
$5.50
Click on photo for
larger view
JACK, 1/4", MONO,
TIP SHUNT, WIRED, Switchcraft™,
LONG BUSHING, ISOLATION WASHERS
Same as the Switchcraft L12A jack but
includes a set of isolation washers.
The
isolation washers keep the jack from making contact with your chassis. This
leaves the jack ungrounded which is needed in certain applications.
Commonly used in older Fender™ Hot Rod Deluxe/Deville and Blues Deluxe/Deville
amps to
replace the fragile input jacks. Part #J-L12AW
$5.99
Click on photo for
larger view
JACK, 1/4", TIP-RING-SLEEVE, OPEN CIRCUIT, WIRED, Switchcraft™ Used with T/R/S plugs for either balanced connections or stereo connections. Also very common in guitars with active pickups, and as the input jack on some effects pedals.
The ring conductor is used in these cases to "turn on" the battery by tying one leg of the battery to ground via the plug.
Fender part number 0013043000. Part #J-12B
$4.35
Click on photo for
larger view
JACK, 1/4", TIP-RING-SLEEVE, OPEN CIRCUIT, WIRED, Switchcraft™, LONG BUSHING Same as the J-12B jack, but with longer (3/8") threaded bushing for mounting in thicker panels. Includes nut and washer. Part #J-L12B
$5.99
Click on photo for
larger view
JACK, 1/4", TIP-SLEEVE, WITH ISOLATED SWITCHING. Switchcraft™ Used with for special switching applications - the two conductors for the switch are completely isolated from both the "hot" audio signal and the ground connection. Used in some vintage amplifiers, including some early Fender™ models.
Isolated switch is normally open - closes when a plug is inserted. Part #J-13
$10.50
Click on photo for
larger view
JACK, 1/4", TIP-SLEEVE, WITH TRANSFER SWITCHING. Switchcraft 13A Jack. Used with for special switching applications - the tip contacts one terminal when no plug is inserted, and contacts a different terminal with the plug in place. Used in a number of Fender™ models, both vintage and modern as the extension speaker jack (ex: Blues and Hot Rod Deluxe and Deville models). Original
Fender™ part number 0041701000
(originally 042701). Also found in some Peavey amps, such as the
Classic 50 speaker jack.
Part #J-13A
$9.95
Click on photo for
larger view
JACK, 1/4", TIP/RING/SLEEVE, WITH
TIP SHUNT. Switchcraft 13B Jack. Tip/Ring/Sleeve
Switchcraft jack. Tip has a shunt contact, ring contact is open
circuit. Part #J-13B
$9.95
Click on photo for
larger view
RCA JACK, PANEL MOUNT
Exact
replacement for the reverb tank and footswitch jacks on the rear panel of
Fender™ Blackface and Silverface amplifiers. Made by Switchcraft. Part #J-122
$2.99
Click on photo for
larger view
Revisit™
RCA JACK, PANEL MOUNT,
CHROME, PHENOLIC BASE MOUNTED - FENDER™ TWEED AMPSSPEAKER JACK.
RCA Phono Jack, chassis mount. 11/16" mounting hole spacing, black phenolic
base, round. Chrome RCA jack. Used as the speaker jack in some Fender Tweed amps from the 1950s,
as well as the Fender™ blackface and silverface Champ, VibroChamp and Bronco
Amps from the 60s and 70s. Also used in vintage USA-Made Accutronic Reverb Tanks
made before 2010. Black phenolic base. Part #J-351
$3.50
Click on photo for
larger view
FENDER
HEADPHONE OR AUXILAIRY JACK - MUSTANG AMPLIFIERS Fender part number 0082046000.
Used only in the Mustang series of amps as the 1/8" stereo headphone or aux jack. Part #J-820
$5.99
Click on photo for
larger view
JACK NUT, PLASTIC, BRITISH STYLE, REPLACEMENT FOR Marshall™ AND OTHERS.
Note: Replaces most black plastic jack nuts EXCEPT for
Roland. Will NOT fit Roland jacks.
Replacement jack nut as found on the J-502, J-503, J-504, J-505, J-503L and
J-504L jacks. Also fits the J-518 and J-519 jacks. Part #J-5NT
$0.50
Click on photo for
larger view
NUT, NICKEL, REAN TYPE, Fender™, AMPS 1999 - Present. Fender™ nut, fits J-508 and J-509 jacks. (Note: you can use this nut on the Cliff J-502, J-503, J-504, J-505, J-503L and J-504L jacks as well, if you wish to change your amps appearance.) Part #J-510
$ 0.85
Click on photo for
larger view
WASHER, FOR BRITISH STYLE (CLIFF) JACKS. This washer goes behind the faceplate on British style plastic nut and
chrome nut jacks to provide proper spacing. Jacks come with the
washers included, but the washers are easily lost. Without the washers,
the jacks will not fit properly. Part #W-583
$0.18
for each washer.
(Jacks not included).
Click on photo for
larger view
JACK NUT MULTI-PACK - SAVE!
6 JACK NUTS, PLASTIC, BRITISH STYLE, REPLACEMENT FOR Marshall™ AND OTHERS. Replacement jack nut as found on the J-502, J-503, J-504, J-505, J-503L and
J-504L jacks. Also fits the J-518 and J-519 jacks. Note:
Replaces most black plastic jack nuts EXCEPT for Roland. Will
NOT fit Roland jacks. Unfortunately, we cannot supply the
Roland jack nuts. Part #J-5NT-6
$2.39
NUT AND WASHER, NICKEL, KOBICONN
OR JALCO TYPE. Fits J-506, J-506A, J-507, J-530, J-531
, J-532, J-533, J-533G,
J-539, J-539G, J-540, J-545, J-6074, J-6075, J-560. Part #JN-916
$0.75
Click on photo for
larger view
SAVE WITH MULTIPACK!
JNUT-38 JACK NUT AND WASHER, METAL,
SWITCHCRAFT™, SET OF 6 Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the
CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™
blackface and silverface), as well as Peavey™ and Switchcraft™
1/4" jacks. Does NOT fit the 24mm Marshall™ pots. Set of
6 washers and 6 nuts. Part #JNUT-38-6
$4.50
(Set of 6 washers and 6 nuts)
JACK NUT AND WASHER, METAL,
SWITCHCRAFT™ Genuine Switchcraft™ nut and washer set for the blackface/silverface Fender™ bias pot, Mesa Boogie pots, and the
CTS or Alpha pots with 3/8" bushing (found on original vintage Fender™
blackface and silverface), as well as Peavey™ and Switchcraft™
1/4" jacks. Does NOT fit the 24mm Marshall™ pots. Part #JNUT-38
$0.89
(Set of 1 washer and 1 nut)
Click on photo for
larger view. Jack is in the picture to demonstrate how the washers
are installed - jack is NOT included with the washers.
INSULATING SHOULDER WASHER, FIBER Pair of fiber insulating shoulder washers for Switchcraft jacks with metal
bushings. Used to mount standard jacks in a 1/2" diameter chassis
hole, while insulating the metal bushing (ground) of the jack from the chassis.
ID 3/8", OD 1/2". Works great when replacing isolated plastic jacks with a
more durable metal jack, which is frequently done on the input jacks of the
Fender™ Hot Rod Deville/Deluxe and Blues Deville/Deluxe. Two washers
are used on each jack, and the "shoulders" are placed facing each other through
the chassis. The washers not only isolate the ground of the jack
electrically for noise reduction, but also stabilize the jack in the 1/2"
diameter hole. Jack shown in picture NOT included. Works
well with the Switchcraft J-11, J-L11, J-12A, J-L12A, J-12B, J-L12B, J-13,
J-13A, J-112APC, J-112BX, J-114BX, J-521 and J-524 jacks. Part #ISW-3069
$0.49
(For a pair of washers. Each jack needs two washers.)
Click on photo for
larger view
JACK LOCK WASHER, METAL Replacement lock washer for all Alpha pots with 3/8" bushing and Mesa Boogie pots,
as well as Switchcraft 1/4" jacks. Part #W-38
$0.49
Click on photo for
larger view
Fender™
STYLE SPEAKER CABINET JACK PLATE ASSEMBLY WITH JACK As used on blackface and silverface speaker cabinet (Bassman, Bandmaster,
Showman, etc). Complete with long-bushing Switchcraft jack
with nut and trim washer, and two
nickel jack ferrules for the inside and outside of
the cabinet back. For wood panels between 3/8 inch and 1/2 inch thick.
Keep your vintage Fender™ cabinet looking original!
Part #JPC-577
$16.95
Click on photo for
larger view
JACK PLATE, BLACK METAL, SINGLE 1/4" JACK, 2" OUTSIDE DIAMETER. Similar in style to vintage Fender™ jack plates. Works well with the Switchcraft J-11 1/4" jacks
that we carry. Hole is 3/8", for most Switchcraft type jacks. Easy to install, economical.
Includes 3 black oxide coarse-thread mounting screws, #6x3/4".
Jack not included - order separately. For size specifications, click here. Part #JP-180
$1.89
Click on photo for
larger view
Revisit™
JACK PLATE COMPLETE WITH
SWITCHCRAFT #11 JACK.
Switchcraft #11 jack preinstalled with lock washer and trim washer. Outside diameter 2 inches (51mm). Minor assembly required. Designed to fit flush against a 1 1/8" (29mm) cabinet hole. Easy to install - drill 1 1/8" hole in cabinet, attach speaker wiring to jack and speaker, attach plate to cabinet. Part #JPC-180
$4.95
Strat™, Stratocaster™, Esquire™, Telecaster™, Tele™, Jazzmaster™, Jaguar™, Mustang™, P.Bass™, J.Bass™ and Fender™ are registered trademarks of Fender™ Musical Instruments. The replacement necks and bodies are for a Fender™ or Squier™ by Fender™ guitar or bass. The distinctive headstock designs and the distinctive body designs of the Stratocaster™, Telecaster™, J.Bass™, P.Bass™ and Tele™ Bass are registered trademarks of Fender™ Musical Instruments Co.
Peavey™ is a registered trademark of Peavey™ Electronics Corporation.
Marshall™ is a registered trademark of Marshall™ Amplification Plc.
Mesa Boogie™ is a registered trademark of MESA/Boogie™ Ltd.
AmpRepairParts.com and Studio Sound Electronics are not affiliated with these companies.
All company names, logos and product names mentioned on these pages are trademarks of their respective owners.
JACK,
9-PIN Low Profile, 1/4",
Fender™.
Used in a few unique Fender models. Nut and washer are NOT included.
Chrome trim ring.
MOUNT, Switchcraft™
STYLE, NON-ISOLATED
Both tip and
ring conductors are switched (normally closed). 5 pins. Used in Peavey™,
Mesa/Boogie, Mackie and
many other brands.
Replaces Switchcraft 114BPCX and 114BPCSX. Nut and washer included.
(normally
closed), ring conductor is not switched. 4 pins for inserting into PC
board, metal bushing. Nut and washer included. Genuine Switchcraft™
Tip is
open, ring is switched (normally
closed). 4 pins for inserting into PC board, metal bushing. Unusual arrangement
used in special applications. Nut and washer included. Genuine Switchcraft™
JACK,
1/4", CHROME NUT, CLOSED CIRCUIT, PC MOUNT, USED IN FENDER™
CHAMPION 600.
Input jack for the Champion 600 reissue. Stereo T/R/S jack, no
switching. Fender part number 0073909049, 0073909000,
007-3909-049. Nut and washer included.
JACK, 1/4", TIP-RING-SLEEVE, OPEN CIRCUIT, WIRED, Switchcraft™
- the two conductors for the switch are completely isolated from both the "hot" audio signal and the ground connection. Used in some vintage amplifiers, including some early Fender™ models.
Isolated switch is normally open - closes when a plug is inserted.
Fender™ part number 0041701000
(originally 042701). Also found in some Peavey amps, such as the
Classic 50 speaker jack.
Revisit™
RCA JACK, PANEL MOUNT,
CHROME, PHENOLIC BASE MOUNTED - FENDER™ TWEED AMPS
SPEAKER JACK.
RCA Phono Jack, chassis mount. 11/16" mounting hole spacing, black phenolic
base, round. Chrome RCA jack. Used as the speaker jack in some Fender Tweed amps from the 1950s,
as well as the Fender™ blackface and silverface Champ, VibroChamp and Bronco
Amps from the 60s and 70s. Also used in vintage USA-Made Accutronic Reverb Tanks
made before 2010. Black phenolic base.
WARNING: These products may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
