Replacement Foot Switches / Parts




Description & Part No.

Price

Purchase


Click on photo for
larger view

FOOT SWITCH, CARLING BRAND, SPDT
Found in many type of footswitches, including the earlier versions of the Dunlop® Crybaby Wah pedals (NOT the version F - see FS-435 below for Crybaby GCB-095F).  Has 3 electrical terminals (single pole, double throw)Solder lugs for wire.
Part #FS-492

$9.95

FOOT SWITCH, CARLING BRAND, SPST, REPLACEMENT FOR Fender®, ETC.
Carling SPST footswitch. Used in Fender® etc. Reverb/tremolo/channel switching pedals.  Has 2 electrical terminals (single pole, single throw)Solder lugs for wire.
Part #FS-493
$9.95

FOOT SWITCH, MOMENTARY, SPST, NORMALLY OPEN
SPST footswitch,
soft touch pushbutton footswitch. Normally open. These are good for tap tempos, loopers (such as the Electro Harmonix 720 Stereo Looper) and anywhere you want the option for a constant or fast foot tap. They're also ok for hand use as they're not too hard to push with fingers.  Has 2 electrical terminals (single pole, single throw)Solder lugs for wire, normally open.
Part #FS-552
$4.95


Click on photo for
larger view

Fender® RCA VIBRATO SHORTING PLUG   Did you know that on vintage Fender® amps (Blackface, Silverface), the reverb will work without a footswitch plugged in, but the vibrato will not?   This handy-dandy little RCA shorting plug will fix that problem, if you don't own or prefer not to use a footswitch on your vintage 60s or 70s Fender® amp.   Just plug this little RCA plug gadget into the vibrato footswitch jack on the back panel, and your vibrato will come alive.    Turn the intensity knob to zero to cut out the vibrato when this plug is inserted.
Part #FSP-100
$1.99

FOOT SWITCH, CARLING BRAND, DPDT, FOR SWITCHING AND EFFECTS.
Has 6 electrical terminals (double pole, double throw)Solder lugs for wire.
Part #FS-497
$13.95


Click on photo for
larger view
FOOT SWITCH, DPDT
Replacement DPDT footswitch for MXR® and Dunlop® pedals.

Original replacement part for:
Dunlop® BG95 Buddy Guy Wah, Dunlop® GCB95F Crybaby Classic Wah, Dunlop® JD-F2 Fuzz Face Distortion, Dunlop® JH-F1 Hendrix Fuzz Face, Dunlop® JH-OC1 Jimi Hendrix Octavio, MXR® M101 Phase 90, MXR® M102 Dyna Comp, MXR® M103 Blue Box, MXR® M104 Distortion+, MXR® M107 Phase 100, MXR® M134 Stereo Chorus, MXR® M169 Carbon Copy Analog Delay, MXR® MC401 Custom Audio Electronics Boost, MXR® MC404 Custom Audio Electronics Wah, Dunlop® SW95 Crybaby Slash Wah

Part #FS-435
$15.95


Click on photo for
larger view
FOOT SWITCH, SPDT, LATCHING, FOR SWITCHING AND EFFECTS - Marshall® TYPE.
Has 3 electrical terminals (single pole, double throw).   Solder lugs for wire. Commonly found in Marshall® footswitch boxes, as well as other brands.  Marshall® part number SWP802.
Part #FS-398
$3.95

FOOT SWITCH, DPDT, LATCHING, FOR SWITCHING AND EFFECTS.
Electrically equivalent to FS-497, but with a smaller switch body.  Has 6 electrical terminals (double pole, double throw).   Solder lugs for wire connections.  Used in many brands of effects pedals and footswitches.
Original footswitch for Dunlop® Fuzz Face JD-F2. Dunlop® part number ECB136
Part #FS-498
$3.95


Click on photo for
larger view
FOOT SWITCH, SPDT, LATCHING, PC MOUNT, FOR SWITCHING AND EFFECTS - Marshall® TYPE
Electrically equivalent and physically the same body size as the FS-398, but made for direct connection to a PC board.  Found in the some Marshall® and Fender® footswitch boxes with PC board design. Has 3 electrical terminals (single pole, double throw).
Part #FS-398-PC
$3.95

FOOT SWITCH, DPDT, LATCHING, PC MOUNT, FOR SWITCHING AND EFFECTS.
Electrically equivalent and physically the same body size as the FS-498, but made for direct connection to a PC board.  Found in the Line 6® XPS-AB power supply for their Variax guitars.  Has 6 electrical terminals (double pole, double throw).
Part #FS-498-PC
$3.95


Click on photo for
larger view
FOOT SWITCH, ALPHA MINIATURE DPDT, LATCHING, PC MOUNT, FOR SWITCHING AND EFFECTS.
Smaller body than the FS-498-PC, this switch is used in many stomp boxes.  The physical size of the pushbutton is the same as all of the other switches - only the rectangular body of the switch is smaller for more compact spaces.  This is a "firm-click" switch - not a momentary.   Switch is marked "L" on the side (for locking).  This is a shorter version than used in MXR® pedals - will not fit MXR®!    Order the D-ECB554 for MXR® pedals.
Part #FS-211-PC
$6.95


Click on photo for
larger view
FOOT SWITCH, ALPHA DPDT, LATCHING, SOLDER LUGS, FOR SWITCHING AND EFFECTS.
This switch is the same as the FS-211-PC, except it has solder lugs for wire attachment.   Made for effects boxes that do not have a PC board under the footswitch.  The physical size of the pushbutton is the same as all of the other switches - only the rectangular body of the switch is smaller for more compact spaces.  This is a "firm-click" switch - not a momentary.   Switch is marked "L" on the side (for locking).
Part #FS-211
$6.95


Click on photo for
larger view
FOOT SWITCH, ALPHA DPDT, MOMENTARY, PC MOUNT, FOR SWITCHING AND EFFECTS.
This switch is the same as the FS-211-PC, except it is momentary (no firm 'click') for those pedals which require a momentary switch.  Switch is marked "M" on the side for momentary.   Pins for PC board mounting.  The physical size of the pushbutton is the same as all of the other switches - only the rectangular body of the switch is smaller for more compact spaces.  Note:   With momentary PC Mount switches, it is necessary to check the pins with a meter and determine the normally open and normally closed pins, comparing to the original switch and design before installing.  Otherwise, it is possible to install a momentary switch "backwards" (reversed 180 degrees) and the device will not work properly.

Part #FS-211-PC-M
$6.95


Click on photo for
larger view
FOOT SWITCH, ALPHA DPDT, MOMENTARY, SOLDER LUGS, FOR SWITCHING AND EFFECTS.
This switch is the same as the FS-211-PC-M, except it has solder lugs for wire attachment.  This switch is momentary (no firm 'click') for those pedals which require a momentary switch.  Switch is marked "M" on the side for momentary.    Made for effects boxes that do not have a PC board under the footswitch.  The physical size of the pushbutton is the same as all of the other switches - only the rectangular body of the switch is smaller for more compact spaces.  Note:   With momentary switches, it is necessary to check the pins with a meter and determine the normally open and normally closed pins, comparing to the original switch and design before wiring.  Otherwise, it is possible to install a momentary switch "backwards" (reversed 180 degrees) and the device will not work properly.
Part #FS-211-M
$6.95


Click on photo for
larger view
FOOT SWITCH, ALPHA MINIATURE DPDT, LATCHING, PC MOUNT, FOR SWITCHING AND EFFECTS.
Smaller body than the FS-498-PC, this switch is used in many Dunlop®/MXR® stomp boxes. Used in later revisions of the MXR® Micro Amp, Carbon Copy, and others.   Also used in the later CSP101SL and M101 versions of the MXR® Phase 90, MXR® M107 Phase 100, MXR® Dime Distortion, MXR® Bass Octave Deluxe, MXR® Custom Badass Modified O.D., MXR® Custom Badass 78 Distortion, MXR® Bass Distortion, MXR® Bass Envelope Filter, MXR® Bass Fuzz Deluxe, MXR® Bass Compressor, MXR® Fullbore Metal, MXR® M117R Flanger, MXR® Supercomp, MXR® Microamp, MXR® M134 Stereo Chorus, MXR® M135 SmartGate, MXR® M148 Micro Chorus, M169 Carbon Copy  .   Dunlop® part number ECB554. The physical size of the pushbutton is the same as all of the other switches - only the rectangular body of the switch is smaller for more compact spaces.  This is a "firm-click" latching switch - not a momentary.   Switch is marked "L" on the side (for locking).  This switch is NOT the same as the FS-211-PC switch - the D-ECB554 is an extended length switch for Dunlop®® / MXR® pedals only.
Part #D-ECB554
$9.95

FOOT SWITCH, DPDT, MOMENTARY, FOR SWITCHING AND EFFECTS.
Made for switching and effects units which require a momentary connection rather than a "hard" connection (no "click").  Solder lugs for wire.  Note:   With momentary switches, it is necessary to check the pins with a meter and determine the normally open and normally closed pins, comparing to the original switch and design before wiring.  Otherwise, it is possible to install a momentary switch "backwards" (reversed 180 degrees) and the device will not work properly.
Part #FS-503
$3.95


Click on photo for
larger view
FOOT SWITCH, SPDT, MOMENTARY, FOR SWITCHING AND EFFECTS.
Important:
  This is one of two types of momentary 3-pin SPDT footswitches using the same footprint.   Click on the diagram to the left, compare the switching with your requirements.   The other switch is the FS-602-PC, with the opposite switching logic.  Customer is responsible for testing and selecting the switch with the correct switching logic - Studio Sound Electronics is not responsible if the wrong switch is selected.  Made for switching and effects units which require a momentary connection rather than a "hard" connection (no "click").  PC terminals.  Has 3 terminals.

Part #FS-502-PC
$3.95


Click on photo for
larger view
FOOT SWITCH, SPDT, MOMENTARY, FOR SWITCHING AND EFFECTS.
Important:
  This is one of two types of momentary 3-pin SPDT footswitches using the same footprint.   Click on the diagram to the left, compare the switching with your requirements.   The other switch is the FS-502-PC, with the opposite switching logic.  Customer is responsible for testing and selecting the switch with the correct switching logic - Studio Sound Electronics is not responsible if the wrong switch is selected.  Made for switching and effects units which require a momentary connection rather than a "hard" connection (no "click").  PC terminals.  Has 3 terminals.   Used in the 5-way foot controller on the Marshall® TSL-100 amps for the clean, crunch and lead switches.

Part #FS-602-PC
$3.95

FOOT SWITCH, DPDT, MOMENTARY, FOR SWITCHING AND EFFECTS.
Made for switching and effects units which require a momentary connection rather than a "hard" connection (no "click").  PC terminals.   Used in the 5-way foot controller on the Marshall® TSL-100 amps for the reverb and effects switches.    Marshall® Part number SWTP-00047.   Also fits some Blackstar® HT Dual Footpedals.    Blackstar® part #MCSWH02014.  Note:   With momentary PC Mount switches, it is necessary to check the pins with a meter and determine the normally open and normally closed pins, comparing to the original switch and design before installing.  Otherwise, it is possible to install a momentary switch "backwards" (reversed 180 degrees) and the device will not work properly.
Part #FS-503-PC
$3.95

FOOT SWITCH, 3PDT, SOLDER LUGS, LATCHING, FOR SWITCHING AND EFFECTS.
Has 9 electrical terminals (3 pole, double throw).     Commonly found in effects pedals which have "true bypass".   Solder lugs for wire.
Part #FS-501
$5.95


Click on photo for
larger view
FOOT SWITCH, 3PDT, PC MOUNT, LATCHING, FOR SWITCHING AND EFFECTS.
Has 9 electrical terminals (3 pole, double throw)    Commonly found in effects pedals which have "true bypass".   Made for PC mounting.
Part #FS-501-PC
$5.95


Click on photo for
larger view
FOOT SWITCH, 4PDT, SOLDER LUGS, LATCHING, FOR SWITCHING AND EFFECTS.
Has 12 electrical terminals (4 pole, double throw)     For use in effects pedals which have "true bypass".   Solder lugs for wire.   Four poles allow additional features and switching options for your own design, such as additional LED indicators in addition to "true bypass".   With 4PDT, the options you can create in switching are limited only by your imagination!
Part #FS-504
$9.95

FOOT SWITCH, MOMENTARY, REPLACEMENT FOR BOSS EFFECT PEDALS
Replacement for Boss effects pedals, SPST momentary, push switch. Mounts in square hole approximately .55" x .55" x 1.08" overall length including terminals.
Part #FS-511
$3.49


Click on photo for
 larger view
FOOTSWITCH, PC MOUNT, TACTILE TYPE
Common switch found in Line 6 floor pedals (such as the Pod XT Live, DL4), Digitech floor controllers (such as the Control ONE), and older DOD pedals.   12mm x 12mm (about 1/2" x 1/2" x 1/4" tall).  Line 6 part number 24-31-0100.
Part #FS-100
$1.95


Click on photo for
 larger view
FOOTSWITCH, PC MOUNT, TACTILE TYPE
Common switch found in Ibanez effects pedals, such as the TS9 Tube Screamer.   12mm x 12mm (about 1/2" x 1/2").   Height of switch from under the base to the top of the plunger is about 7mm.   Data Sheet here.
Part #FS-621
$0.99


Click on photo for
larger view
TACT SWITCH, 6mm X 6mm.  1mm PLUNGER HEIGHT
6mm x 6mm square (¼" x ¼").  Body of switch is 3.0mm tall (without plunger).    Plunger extends 1.0mm above top of switch (about the thickness of a credit card).   Used in effects pedals, front panel controls, etc.  4 legs (2 of them are redundant on each side, so the switch is SPST, normally open, momentary).     For through-the-hole mounting on PC boards.
Part #TS-5126
$0.99


Click on photo for
larger view
TACT SWITCH, 6mm X 6mm.  1.5mm PLUNGER HEIGHT
6mm x 6mm square (¼" x ¼").  Body of switch is 3.0mm tall (without plunger).    Plunger extends 1.5mm above top of switch.   Used in effects pedals, front panel controls, etc.  4 legs (2 of them are redundant on each side, so the switch is SPST, normally open, momentary.    For through-the-hole mounting on PC boards.   Fits the Line 6 Alchemist, Bass POD XT Live, FBV Shortboard MKII, Floor POD Plus, M9, M13, POD HD300, POD HD400, POD HD500, POD X3 Live, POD XT Live, Spider Valve HD100, Spider Jam, Spider IV SERIES, Spider IV1508, HD500X.    Line 6 part number 24-31-1105
Part #TS-5127
$0.99


Click on photo for
larger view
TACT SWITCH, 6mm X 6mm.  1.5mm PLUNGER HEIGHT, 2 LEGS
6mm x 6mm square (¼" x ¼").  Body of switch is 3.0mm tall (without plunger).    Plunger extends 1.5mm above top of switch.   Used in effects pedals, front panel controls, etc.  2 legs, SPST, normally open, momentary.     For through-the-hole mounting on PC boards.   Fits a number of guitar processors, amplifiers, and effects pedals of various brands.
Part #TS-5144
$0.99


Click on photo for
larger view
9V BATTERY CLIP.
Commonly found in effects boxes.

Part #9VBC
$0.45


Click on photo for
larger view
9V BATTERY HOLDER
No more batteries rattling around inside your effects pedals.    This economical solution can be attached to the inside wall of your pedal with hot glue, velcro, or screws, and holds a 9V battery securely.
Part #BH-28019
$1.50

  Footswitch Nuts
Photo Description & Part No. Price Purchase

Click on photo for
larger view

Hex footswitch nut, pack of 4

These replacement nuts fit all Carling® brand footswitches and toggle switch and some (but not all) other switches which are not made by Carling®.   Carling® toggle switches are used in Fender® amps.  Hex outer surface (9/16"), M12 thread for 15/32" bushing.

Part HFN-4

$0.99
(for a pack of 4 nuts)


Click on photo for
larger view

White Nylon Footswitch Washer

This replacement white nylon washer fits all standard footswitches.   3/4" outside diameter (19mm), 1/2" inside diameter (12.5mm), 3/64" thick (1.3mm).   The plastic washer helps keep the painted surface of the effects pedal from being scratched when removing or installing the nut.    Made to fit Dunlop®, Electro-Harmonix, MXR®, Foxx, Heil, Morley, FullTone, Line 6, Tech 21, AnalogMan, Digitech, DOD, Ibanez, Keeley, Maxon, MuTron, T-Rex, TC Electronics, ProCo, Wampler, VooDoo Lab, Morley, Roger Mayer, Hughes & Kettner®, Visual Sound, Marshall® , Carl Martin, Seymour Duncan, and many more.

Part WFW-716

$1.00

Note:  Limited quantities available



Foot Switch Box Wiring






Click on photo for
larger view

Revisit™ VINTAGE Fender® FOOTSWITCH CABLE REPAIR KIT
Restore your footswitch with the original style wiring that Fender® originally used in the Blackface and early Silverface era!   This kit includes 12.5 feet of original Fender® style dual cable (one shielded cable for the reverb switch and a single unshielded wire for the reverb).   Also included are two P-121 RCA plugs for attaching to the cable end.   The switches for the footswitch box are below (FS-493).   As long as you have a good housing, you can bring your original footswitch back to life!  Soldering capability required.
Part #FFC-12
$7.95


Click on photo for
larger view
FOOT SWITCH, CARLING BRAND, SPST, REPLACEMENT FOR Fender®, ETC.
Carling SPST footswitch. Used in Fender® etc. Reverb/tremolo/channel switching pedals.  Has 2 electrical terminals (single pole, single throw)Solder lugs for wire.
Part #FS-493
$9.95
