Tube Hardware & Accessories



Click on photo for
larger view
Gold Jacket Gold-Plated Solid-State Tube Rectifier Replacement.
Replaces 5AR4, GZ34, 5U4, 5Y3 rectifier tubes.  Use when less 'sag' is desired in the power supply.   Gold-plated pins for superb conduction.   1.19" in diameter, 0.86" tall (not including pins and center post).   Gold-plated metal housing with white ceramic base.   One year warranty, triple-diode construction for reliability and long service.   The "Gold Standard" in tube rectifier replacement.

NOTE! Because there is no warm up of a rectifier tube when using this solid state device, it is absolutely necessary that a standby switch is used in conjunction with this device.   Do not install in an amplifier that does not have a standby switch - always use the standby switch in amps so equipped when using the 5RTR.
Part #5RTR

$13.95


Click on photo for
larger view
Revisit™ Solid-State Tube Rectifier Replacement.
Replaces 5AR4, GZ34, 5U4, 5Y3 rectifier tubes.  Use when less 'sag' is desired in the power supply.  1.31"  diameter, 0.89" tall (not including pins and center post).

NOTE! Because there is no warm up of a rectifier tube when using this solid state device, it is absolutely necessary that a standby switch is used in conjunction with this device.   Do not install in an amplifier that does not have a standby switch - always use the standby switch in amps so equipped when using the 5SSR.
Part #5SSR

$9.95


Click on photo for
larger view
Tube Box, Fits 6L6GC, Thin EL34
1-11/16" x 1-5/8" x 4-15/16" Heavy plain white boxes with dividers to cushion tube.  Fits 6L6, 5881, most thin EL34s

Part #TB-249
$0.32


Click on photo for
larger view
TUBE SHIELD, BAYONET "PUSH AND TWIST" TYPE, ALUMINUM, 1 15/16" TALL.  Includes new base, if needed.  Spring in top of shield fits over the tube.  Fits 12AX7A and similarly sized preamp tubes. Replacement for Fender® and many other brands.  Holes in base spaced 1 1/8" apart.

Part #TS-325S
$1.95


Click on photo for
larger view
TUBE SHIELD, BAYONET "PUSH AND TWIST" TYPE, ALUMINUM, 1 15/16" TALL, SET OF 6.  Includes new bases, if needed.  Spring in top of shield fits over the tube.  Fits 12AX7A and similarly sized preamp tubes. Replacement for Fender® and many other brands.  Holes in base spaced 1 1/8" apart.   This is a great kit to replaced all 6 of the tube shields in many Fender® amps with 6 preamp tubes.

Part #TS-325S-6
$8.95


Click on photo for
larger view
TUBE SHIELD, BAYONET "PUSH AND TWIST" TYPE FOR MATING WITH PREFORMED CHASSIS HOLE, ALUMINUM, 2" TALL, SPRING IN TOP OF SHIELD WHICH FITS OVER THE TUBE.   Fits 12AX7A and similarly sized preamp tubes.  Comes with rubber gasket for sealing and noise damping with chassis.  Replacement for Marshall® and some other brands.
Part #TS-601
$1.95


Click on photo for
larger view
TUBE RETAINER WITH SPRINGS, DESIGNED FOR 6L6 OR EL34 TUBES.   USED IN Marshall® AND MANY OTHER AMPS.
Part #TC-141
$1.95


Click on photo for
larger view
LARGE TUBE RETAINER WITH SPRINGS, DESIGNED FOR 6550 OR KT-88 TUBES.

Part #TC-143
$2.25


(TUBE NOT INCLUDED)

Click on photo for
larger view

Revisit™ PRE-AMP TUBE DAMPER RINGS.   Use two (or three) of these rings around a pre-amp tube to reduce noise and microphonics.  An economical alternative to more expensive tube dampers.   Will withstand high temperatures of pre-amp tubes, reusable when you change tubes.   Set of 6 rings - will equip either 2 or 3 tubes, depending on the number of rings you choose for each tube.
Part #PTD-6
$2.99
(Set of 6 rings)


Click on photo for
larger view
RUBBER RING FOR TC-141 TUBE RETAINER, DESIGNED FOR 6L6 OR EL34 TUBES.   Cushions tube against the springs, prevents rattle.  High temperature.    Only works with the spring type tube retainer such as the TC-141.   Will also fit 6V6 tubes, provided your amp has a spring type retainer for these tubes.
Part #RR-141
$1.00


Click on photo for
larger view
TUBE RETAINER WITH GRIP TEETH, DESIGNED FOR OCTAL TUBES WITH PHENOLIC BASE SUCH AS 6L6 OR EL34.   Used in Fender® and many other amps.     1 1/2" mounting centers.  Made by Belton.  Fender part number 099072500.
Part #TC-142
$1.95


Click on photo for
larger view
TUBE RETAINER FOR EL84 OR 6BQ5 TUBES.   2.8" TALL TUBE MAXIMUM.    USED IN VOX, SUPRO, AND MANY OTHER AMPS.  1 1/8" MOUNTING CENTERS.
Part #TR-144
$1.95


Click on photo for
larger view
TUBE RETAINER FOR 12AX7, 12AT7, OR 12AU7 TUBES.   2.1" TALL TUBE MAXIMUM.    USED IN VOX, SUPRO, AND MANY OTHER AMPS.  1 1/8" MOUNTING CENTERS.
Part #TR-146
$1.95


Click on photo for
larger view
Fender® Vintage Amp (60s Blackface and 70s Silverface) Power Tube Socket replacement kit.    For vintage Fender® amps (NOT Reissues!) from the original blackface and silverface eras which have two power tubes (6L6 or 6V6).   Contains two phenolic 8-pin sockets, two "bear trap" retainers, four mounting screws, two 470 ohm screen grid resistors (Metal-Film Flameproof for safety), and two carbon composition 1500 ohm control grid resistors.   Princeton and Princeton Reverb do not need the resistors.   Perfect for Vibrolux Reverb, Vibroverb, Super Reverb, Deluxe Reverb, Pro Reverb, Bassman, Bandmaster Reverb, Tremolux, etc.
Part #FPTSK-2
$10.95


Click on photo for
larger view
Fender® Vintage Amp (60s Blackface and 70s Silverface) Power Tube Socket replacement kit.    For vintage Fender® amps (NOT Reissues!) from the original blackface and silverface eras which have four power tubes (6L6).   Contains four phenolic 8-pin sockets, four "bear trap" retainers, eight mounting screws, four 470 ohm screen grid resistors (Metal-Film Flameproof for safety), and four carbon composition 1500 ohm control grid resistors.   Perfect for Twin Reverb, Showman and Dual Showman, Quad Reverb, Bassman 100, etc.
Part #FPTSK-4
$20.95


Click on photo for
larger view
OCTAL TUBE KEYWAY, SET OF 2
If you have a cherished octal power tube or rectifier with a broken keyway, here is a great solution. By cleaning the remainder of the broken keyway from the tube base and properly installing this keyway replacement (a little dab of silicone sealant works great to hold it in place), your tube can safely be reinstalled into your equipment.   These great tube-savers are sold in sets of 2.   Note:  when using an adhesive to secure the keyway to the tube base, DO NOT use a water-based glue.   Silicone sealant (RTV) which is acryllic-based or butyl-based is fine.   Latex sealant or hot-glue is NOT.
Part #OTK8-2
$5.99
(for a set of 2 tube keyways)


Click on photo for
larger view
PHENOLIC TUBE SOCKET FOR OCTAL TUBES.  EXACT REPLACEMENT FOR VINTAGE FENDER, VINTAGE Marshall® (including the JCM900 Series), and many others.    Fits 6L6, EL34, 6V6 output tubes, and 5U4, 5Y3, and GZ34 rectifier tubes.   For 1" to 1 1/8" hole.  Top mounting (mounted from the outside of the chassis), mounting holes spaced 1 1/2" apart.
Part #TS-8-600
$2.99


Click on photo for larger view

CERAMIC 8-PIN PC MOUNT OUTPUT TUBE OR RECTIFIER TUBE SOCKET, crimped bracket, bottom mount 1 1/4", top mount 1" to 1 1/8", 1 1/2" mounting centers, 1" to 1 1/4" chassis hole.  Fits 6L6, EL34, 6V6 output tubes, and 5U4, 5Y3, and GZ34 rectifier tubes. Used in Peavey and other brands where the tube socket is mounted to a PC board.   Click here for additional specs.   Fender part number 0057238000.
Part #TS-8-807

$3.50


Click on photo for larger view

CERAMIC 8-PIN WIRED OUTPUT TUBE OR RECTIFIER TUBE SOCKET, crimped bracket, bottom mount 1 1/4", top mount 1" to 1 1/8", 1 1/2" mounting centers, 1" to 1 1/4" chassis hole.  Fits 6L6, EL34, 6V6 output tubes, and 5U4, 5Y3, and GZ34 rectifier tubes.  Click here for additional specs.   Fender part number 0990724000.
Part #TS-8-807W

$3.50



Click on photo for
larger view

Socket - Belton, Micalex, 8 Pin, Octal PC Mount, Long Lead Micalex, PC mount, long leads (Belton) - MB/MT. 1 ˝" mounting centers 1 Ľ" chassis hole. Applicable for use with all types of electric and electronic equipment using vacuum tubes.  Paddle saddle mounting, easy mount with the saddle of extruded screw hole.   Phosphorous bronze pin terminal with tin plating, glass fiber field PPS Insulating material
Part # TS-8-209

$3.50


Click on photo for larger view

Belton 8 pin socket, Micalex, for PC board mounting  1 1/2" & 1 3/16" mounting centers, 1 3/16" chassis hole.  Fits 6L6, EL34, 6V6 output tubes, and 5U4, 5Y3, and GZ34 rectifier tubes. Used in Marshall® , Peavey and other brands where the tube socket is mounted to a PC board.   Click here for additional specs.
Part #TS-8-BEL

$3.99


Click on photo for
larger view
FENDER® STYLE MICALEX TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  INCLUDES INTEGRAL BASE FOR TWIST-LOCK TUBE SHIELD.        Fits 12AX7, 12AU7, 12AT7, etc.   Sturdy Micalex construction, for 3/4"  hole.  Solder tabs for wire connections.   Top mounting (mounted from the outside of the chassis), mounting holes spaced 1 1/8" apart.   Designed to work with the TS-325S tube shield, or vintage Fender® tube shields.   Used in Fender® vintage Blonde, Brownface, Blackface, Silverface and some early Rivera designs.   Also applicable to early Marshall® designs.  Fender part number 0023606049.
Part #TS-9-700
$2.69


Click on photo for
larger view
6-PACK OF FENDER® STYLE MICALEX TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  INCLUDES INTEGRAL BASE FOR TWIST-LOCK TUBE SHIELD.        Fits 12AX7, 12AU7, 12AT7, etc.   Sturdy Micalex construction, for 3/4"  hole.  Solder tabs for wire connections.   Top mounting (mounted from the outside of the chassis), mounting holes spaced 1 1/8" apart.   Includes mounting screws.  Designed to work with the TS-325S tube shield, or vintage Fender® tube shields.   Used in Fender® vintage Blonde, Brownface, Blackface, Silverface and some early Rivera designs.   Also applicable to early Marshall® designs.   Pack of 6 tube sockets and 12 mounting screws.   Fender part number 0023606049.
Part #TS-9-700-6
$11.99
(for 6 sockets and 12 mounting screws)


Click on photo for
larger view
TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  EXACT REPLACEMENT FOR MANY MAKES AND MODELS OF AMPS WITH HAND-WIRED TUBE SOCKETS.      Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.   For 3/4"  hole.  Bottom mounting (mounted from the inside of the chassis), mounting holes spaced 1 1/8" apart.   Designed to work with the TR-144 or TR-146 tube retainers, or the TS-325S tube shield.
Part #TS-9-601
$2.49


Click on photo for
larger view
TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  EXACT REPLACEMENT FOR MANY MAKES AND MODELS OF AMPS WITH HAND-WIRED TUBE SOCKETS.      Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.   For 3/4"  hole.  Top mounting (mounted from the outside of the chassis), mounting holes spaced 1 1/8" apart.   Designed to work with the TR-144 or TR-146 tube retainers, or the TS-325S tube shield.
Part #TS-9-610
$2.49


Click on photo for
larger view
TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  EXACT REPLACEMENT FOR MANY MAKES AND MODELS OF AMPS WITH PC-MOUNT TUBE SOCKETS.      Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.   For 3/4"  hole.  Top mounting (mounted from the outside of the chassis), mounting holes spaced 1 1/8" apart.   Designed to work with the TR-144 or TR-146 tube retainers, or the TS-325S tube shield.   Pins for insertion into a main PC board inside the chassis.
Part #TS-9-610-PC
$2.49


Click on photo for
larger view
9 pin Belton micalex socket for PC board mouting, 3/4" PC hole, 1 1/8" mounting centers.     Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.   Used in Marshall® , Peavey® and other brands where the tube socket is mounted to a PC board.   Click here for additional specs.
Part #TS-9-BEL
$2.79


Click on photo for
larger view
TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  PC MOUNT, CERAMIC.    9 pin ceramic PC mount socket, stand-off mounting, 0.82" diameter., 3/4" tall.   Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.
Part #TS-9-223
$2.49


Click on photo for
larger view
TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  PC MOUNT, MICALEX.    9 pin ceramic PC mount socket, stand-off mounting, 3/4" diameter, 3/4" tail diameter.  For bottom mounting (mounted from the inside of the chassis, below the chassis hole).   Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.    Micalex replacement for the tube sockets in the Fender® Blues Junior, Pro Junior, and the Fender® Hot Rod Deluxe/Deville and Blues Deluxe/Deville.   Fender part number 0029167049.
Part #TS-9-620
$1.99


Click on photo for
larger view
3-PACK, TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  PC MOUNT, MICALEX.    9 pin ceramic PC mount socket, stand-off mounting, 3/4" diameter, 3/4" tail diameter.  For bottom mounting (mounted from the inside of the chassis, below the chassis hole).   Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.  Fender part number 0029167049.    This 3-pack replaces all of the sockets for the 12AX7 preamp tubes in the Fender® Blues Junior, Hot Rod Deluxe/Deville and Blues Deluxe/Deville.
Part #TS-9-620-3
$4.99
(for a 3-pack of tube sockets)


Click on photo for
larger view
5-PACK, TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  PC MOUNT, MICALEX.    9 pin ceramic PC mount socket, stand-off mounting, 3/4" diameter, 3/4" tail diameter.  For bottom mounting (mounted from the inside of the chassis, below the chassis hole).   Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.    Fender part number 0029167049.    This 5-pack replaces all 5 tube sockets in the Fender® Blues Junior.
Part #TS-9-620-5
$7.95
(for a 5-pack of tube sockets)


Click on photo for
larger view
10-PACK, TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  PC MOUNT, MICALEX.    9 pin ceramic PC mount socket, stand-off mounting, 3/4" diameter, 3/4" tail diameter.  For bottom mounting (mounted from the inside of the chassis, below the chassis hole).   Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.    Fender part number 0029167049.    Used in the Fender® Blues Junior, and the Fender® Hot Rod Deluxe/Deville and Blues Deluxe/Deville.
Part #TS-9-620-10
$12.95
(for a 10-pack of tube sockets)


Click on photo for
larger view
TUBE SOCKET FOR MINIATURE 9-PIN TUBES.  PC MOUNT, CERAMIC.    9 pin ceramic PC mount socket, stand-off mounting, 3/4" diameter, 3/4" tail diameter.  For bottom mounting (mounted from the inside of the chassis, below the chassis hole).   Fits 12AX7, 12AU7, 12AT7, 6BQ5, EL84 tubes.    Used in Gibson® Goldtone series amplifiers.  Ceramic replacement for the tube sockets in the Fender® Blues Junior, and the Fender® Hot Rod Deluxe/Deville and Blues Deluxe/Deville.
Part #TS-9-217
$1.49


Click on photo for
larger view

Fender® SELF-TAPPING SCREWS
Used in vintage Fender® blackface and silverface amps for a variety of tasks.   Used to attach the fiberboard, capacitor pans, power tube sockets, transformers on smaller amps, chokes, etc.   Pack of 6 screws.  Original Fender® part number 029913
Part #SC-410-6
$1.69
(for a pack of 6 screws)
